Understanding an F28 fault code on a Vaillant boiler

The majority of the modern boilers, including combi, system, or regular boilers, have a built-in automatic safety mechanism that protects them from damage. Whenever something goes wrong with the boiler, the safety mechanism triggers automatic shutdown or lockout, and an error code is displayed. These error codes are not universal; each brand has its own set, reflecting different faults or errors.

Vaillant is a famous and quite popular boiler brand in the UK. Like all other modern boilers, it is also equipped with an automatic safety system. Obviously, the very purpose of a safety system is to protect a boiler against potential damage and unnecessary energy/fuel loss. So, when the safety system senses something is not right, it forces the boiler either to lock out or shut down, depending on the severity and nature of the fault. To facilitate users, just as other brands do, Vaillant also has its own set of error and fault codes. These are displayed to warn or alert users that the boiler is experiencing a specific problem and has been locked out or shut down for safety reasons. F28 is among the most common fault codes; every homeowner or tenant has likely experienced it with their Vaillant boiler.

This blog explains everything a homeowner must know about the F28 fault code in Vaillant boilers.

Understanding An F28 Fault Code In Vaillant Boilers

An F28 fault code appears on the Vaillant Boiler’s display panel when the boiler fails to ignite the burner. Typically, the electronic control mechanism of the boiler attempts to ignite the burner three times, but if it fails to detect a flame, a Vaillant boiler enters lockout mode. When it happens, the system displays the code F28, indicating that no flame is detected and the boiler has failed to ignite. The obvious result of this fault would be "no heating" and "no hot water in taps and showers”.

In other words, an F28 fault code appears when the boiler has entered a lockout mode, after the following events:

1.       The boiler has failed to ignite the gas burner.

2.       The boiler has tried to ignite the gas burner three times.

3.       The boiler's safety system has forced it to stop operating to protect it from potential damage and, more importantly, to prevent unsafe gas burning. It also prevents unnecessary gas accumulation in the burning chamber, which could lead to a mishap.

Reasons/Causes of Ignition Failure

While an F28 fault code indicates that the boiler failed to ignite, there are multiple reasons it may have happened. In general, these reasons can be divided into the following major groups.

Disruption In Gas Supply

If a boiler fails to ignite, the first and most likely cause is a faulty gas supply. In most cases, this is one of the most common reasons for a boiler displaying an F28 error code. The possible reasons for a disrupted gas supply may include:

·         The pre-payment gas meter is out of credit.

·         The gas inlet valve is either erroneously or purposely closed by someone.

·         The supplier has temporarily disconnected the gas supply for various reasons, including technical issues, upgrades, or maintenance work.

·         Gas pressure has dropped significantly from the mains.

·         The area is scheduled for a gas outage.

What To Do?

·         The first option is to confirm if the gas supply is disconnected. It can be checked by turning on any other gas appliance. If that appliance also fails to turn on, it can be safely assumed that there is no gas supply.

·         If other gas appliances are working normally, check the gas inlet valve supplying the boiler.

·         Recharge the pre-payment gas meter if the credit has exhausted.

·         Call the gas supplier's helpline to confirm whether there is a scheduled or emergency gas outage in the area.

·         If gas is there but the boiler still can’t ignite, move on to the next check.

Condensate Pipe Is Blocked

Modern boilers are designed to discharge condensate water, produced during normal operation, out of the home. For this purpose, the boiler is connected to a plastic pipe (condensate pipe). This pipe is meant to drain condensate water from the home. In severe cold weather, there is a high likelihood that this pipe will freeze. When it happens, the pipe becomes blocked, disrupting the drainage of condensate water from the home. In such an event, the boiler's safety system prevents ignition, resulting in an F28 fault code.

This can be confirmed by a thorough examination of the condensate pipe. It might have ice on its external part. Another sign is the backing up or dripping of water from the condensate outlet. A common and most relevant sign is that the boiler often stops working in the mornings of the winter season.

What To Do? The frozen condensate pipe can be thawed by pouring warm water onto its exterior, but avoid using hot or boiling water. Once the ice is melted, the boiler should now successfully ignite.

Burner Is Faulty

If there is no interruption in the gas supply and the condensate pipe is not frozen, the next possibility is that the problem lies with an internal component of the boiler, most likely in the ignition chamber. The reasons might be one or more of the following:

·         The ignition electrode is faulty.

·         The electronic system of spark generation is faulty.

·         The gas valve is faulty, preventing proper gas flow.

·         PCB (printed circuit board) has developed a fault.

·         The wiring is faulty.

In the event of any of the above, there will either be no flame or an inconsistent flame, which would trigger the safety mechanism, forcing the boiler to lock out.

What To Do? This is entirely a technical issue that cannot be handled on your own. Only a gas safe registered engineer is authorized to work on these issues.

Flue Is Blocked or The Air Supply Is Restricted

The burning of gas needs sufficient availability of air (oxygen). Another necessary condition for proper combustion is the safe exhaust of flue gases. The boiler may fail to ignite if there is insufficient or no oxygen, or if no safe path is available for the burned gases to exhaust. Over time, the flue or chimney is often blocked by debris. When it happens, the boiler fails to ignite, displaying an error code F28.

What To Do? Again, a blocked flue should not be cleared by you. It is a technical task that can only be performed by a gas safe registered engineer.

Important

·         Reset Option - In some cases, an F28 fault code can be fixed by resetting the boiler. The Vaillant boilers are equipped with a "reset" button. Press it for a few seconds, and the boiler will reset itself. If the boiler still fails to ignite, do not repeat the reset attempt; call a gas-safe registered engineer to fix the problem.

·         Boiler Age – If the boiler has outlived its useful life, typically 10 to 12 years, there is a higher risk of frequent lockouts. Hence, replacing it might be a good option.

·         Annual Gas Safety Service – An annual gas safety inspection is not only a mandatory requirement for landlords under the Gas Safety Regulations of 1998, but it is also very important to maintain your boiler in perfect working condition. Ensure your boiler is serviced annually by a gas-safe registered engineer.

·         Timely Repairs – Timely repair and fault correction are critically important for trouble-free boiler performance. Delayed repairs may result in higher costs and increased energy bills.

Conclusion

An F28 fault code on Vaillant boilers is quite common. While it simply indicates that the boiler failed to ignite, there may be several reasons. The fault code F28 is just a sign of an underlying problem, which may be a disruption in the gas supply, a frozen condensate pipe, a faulty burner component, or any other internal issue with the boiler. Hence, it is important to identify the underlying cause of an F28 fault code.

In most cases, problems such as a frozen condensate pipe or a credit issue with a pre-payment gas meter can be easily resolved on your own. But in more serious cases, such as an internal fault in the burner component or a blocked flue, never try to fix it yourself. These are technical issues that can only be fixed by a qualified boiler engineer, typically a gas safe registered engineer.

Timely repairs and regular service are essential to keeping your boiler in perfect working order throughout the winter. Even more important is the annual gas safety check, which ensures your boiler performs trouble-free.
